SPM rope is a circular braid design developed to give the rope extra protection against wear and tear, without significantly changing the primary characteristics. It is a logical development from the double braid, where the outer protects the inner and both contribute to the strength. In circular braided rope design this duality has been abandoned. The cover is optimized for strength. This results in both a higher strength and a better life expectancy.
Characteristics
Spec Density: 1.14 non floating
Melting Point: 215°C
Abrasion Resistance: Excellent
UV Resistance: Excellent due to jacket
Temperature: 80°C max continuous
Chemical Resistance: Reasonable. Acids, oxidisers & solvents will affect nylon
Diameter: 80mm – 160mm
Dia (mm)
Circ (ins)
Weight (KG/100mtr)
NDBS (KN) Single
NDBS (KN) Grommet
NWBS (KN) Single Leg
NWBS (KN) Grommet
80
10
397
1442
2452
1370
2329
88
11
481
1746
2969
1659
2820
96
12
572
2040
3469
1938
3295
104
13
671
2443
4153
2321
3945
112
14
779
2825
4803
2684
4563
120
15
893
3208
5453
3047
5181
128
16
1020
3610
6137
3430
5830
136
17
1150
4110
6988
3905
6638
144
18
1280
4611
7838
4380
7446
152
19
1425
5111
8689
4855
8254
160
20
1580
5670
9639
5387
9062
Rope is in compliance with OCIMF Equipment Guidelines & ISO 2307
Other sizes can be provided as per the requirement
